MIT2500

CAT IV Insulation testers

■ Insulation testing up to 2.5 kV (New)

and 200 GΩ range in a hand held instrument

■ Guard terminal for high resistance accuracy

(New)

■ Adjustable insulation test voltage from

50 V to 2500 V (New)

■ Stabilised insulation test voltage (New)

■ Rechargeable options for mains and car

charging (New)

■ Single range, faster continuity testing from

0.01 Ω to 1 MΩ (New)

■ Polarisation Index (PI) & Dielectric Absorption

Ratio (DAR)

■ CAT IV 600 V applications

DESCRIPTION

The MIT2500 insulation and continuity tester has been designed for

Electrical and Industrial test applications, where operation voltages

exceed 1000 V and higher insulation test voltages are needed.

The MIT2500 offers both fixed range voltages of 50 V, 100V,

250 V, 500 V, 1000 V and 2500 V, as well as a variable range that

allows any voltage between 50 V and 2500 V to be “dial in”.

This is supported by the new test voltage feedback control, which

maintains the output test voltage to within 2% of the selected

range, even when under test.

The MIT2500 uses the redesigned case, back-stand, and 6 cell

battery compartment, as well as incorporating a Guard terminal

to reduce surface tracking currents that reduce accuracy at higher

voltages.

All instruments are over-moulded for increased protection and

achieve an IP54 weatherproof rating

INSULATION RESISTANCE TESTING

The feedback control insulation test voltage is now accurate

to +2% -0% compared to the original +20%, providing a more

accurate test voltage without the risk of over-voltage damage to

circuits.

A variable range allows the exact test voltage to be selected from

50 V to 999 V in 1 V steps, (1KV to 2.5KV in 10 V steps) providing

1100 test voltage options.

FEATURES INCLUDE:

■ Test voltages (New)

- 50 V, 100 V, 250 V, 500 V, 1000 V, and 2500 V

■ Guard terminal

- Improved performance on higher insulation test ranges

■ 2.5 kV Silicone test leads (New)

- Purpose designed high 2.5 kV silicone test leads are included as

well as standard 1000 V CAT III / 600 V CAT IV general purpose

test leads.

■ Variable test voltage (New)

- Adjustable test voltage from 50 V to 999 V in 1 V steps,

1000 V to 2500 V in 10 V steps

■ 2% Test voltage accuracy

- The output test voltage is maintained within the tolerance of

-0% +2% +2 V

■ Stabilised test voltage

- The voltage is feedback control to ensure it remains within

specification throughout the full test range

■ Test voltage display (New)

- The actual test voltage is displayed on the smaller digital

readout, with the measurement on the larger digital display.

■ Measurement range displayed

– The range voltage is displayed during selection.

■ Measurement voltage display (New)

- The measurement voltage is displayed during the test.

二氧化碳传感器二氧化碳传感器二氧化碳传感器二氧化碳传感器

■ Analogue arc
