DC V 6.000/60.00/600.0V (自动量程)

±0.5%rdg ±3dgt

DC mV 600.0mV

±1.5%rdg ±3dgt

DC 钳形传感器 60.00/200.0A (自动量程)

±1.5%rdg ±3dgt + 传感器度

AC A 6.000/60.00/600.0V (自动量程)

±1.0%rdg ±3dgt [40 - 500Hz]

AC mV 600.0mV

±2.0%rdg ±3dgt [40 - 500Hz]

AC 钳形传感器 60.00/200.0A (自动量程)

±2.0%rdg ±3dgt + 传感器度 [40 - 500Hz]

DC A 6.000/10.00A (自动量程)

±1.5%rdg ±3dgt

AC A 6.000/10.00A (自动量程)

±1.5%rdg ±3dgt[45 - 500Hz]

Ω 600.0Ω/6.000/60.00/600.0kΩ/6.000/40.00MΩ (自动量程)

±0.5%rdg ±4dgt (600Ω),

±0.5%rdg ±2dgt (6/60/600kΩ/6MΩ)

±1.5%rdg ±3dgt (40MΩ)

导通蜂鸣 600Ω (低于90Ω蜂鸣器鸣叫)

二极管测试 开环电压: < 3.0V

电流容量 60.00/600.0nF/6.000/60.00/600.0/1000μF

±2.0%rdg ±5dgt (60/600nF)

±5.0%rdg ±5dgt (6/60/600/1000μF)

频率 ACV 99.99/999.9Hz/9.999/99.99kHz ±0.1%rdg ±3dgt

ACA 99.99/999.9Hz/9.999kHz ±0.1%rdg ±3dgt

负荷 10.0 - 90.0% ±1.0%rdg ±3dgt [50/60Hz]

适用标准 IEC 61010-1 CAT IV 300V / CAT III 600V / CAT II 1000V

IEC 61010-2-033, IEC 61010-031, IEC 61326-2-2 (EMC), EN 50581 (RoHS)

电池

R03 (1.5V) × 2

外形尺寸

155(L) × 75(W) × 40(D)mm

重量

250g Approx. (含电池)

附件 翼型支架, 平展型支架, 7066A (测试线),

8919 (陶瓷保险丝 [10A/600V]) × 1 (包含),

9097 (便携箱), R03 × 2, 使用说明书表表表表
