LED贴片5630红光0.5W波段620-630NM
价格：电议
地区：广东 深圳市
电 话：86 0755 27168227
传 真：86 0755 27167816
-
图文详情
-
产品属性
-
相关推荐
Part Number：HNSR5630B0.9 | |||||||||
Absolute maximum ratings （Ta=25°C） | |||||||||
Parameter | Symbol | Value | Unit | ||||||
Forward current | If | 150 | mA | ||||||
Reverse voltage | Vr | 5 | V | ||||||
Power dissipation | Pd | 0.5 | W | ||||||
Operating temperature range | Top | -25~+80 | °C | ||||||
Storage temperature range | Tstg | -30~+85 | °C | ||||||
Peak pulsing current（1/8 duty f=1KHz） | Ifp | 240 | mA | ||||||
Electro-Optical characteristics (TA=25°C) | |||||||||
Parameter | Test Condition | Symbol | Value | Unit | |||||
Min | Typ | Max | |||||||
Color Temperature | If=150mA | CCT | 620 |
| 630 | K | |||
Forward voltage | If=150mA | Vf | 1.9 | -- | 2.2 | V | |||
Light | If=150mA | φ | 15 |
| 20 | Lm | |||
Viewing angle at 50% IV | -- | 2θ1/2 | -- | 120 | -- | Deg | |||
Reverse current | Vr=5V | Ir | -- | 10 | -- | μA | |||
