专销霍尼韦尔honeywell触力传感器FSS1500NST
价格：电议
地区：上海
传 真：86 21 31391718
-
图文详情
-
产品属性
-
相关推荐
| Sensitivity | 0.10 mV/g min., 0.12 mV/g typ., 0.14 mV/g max. |
| Operating Force (OF) | 0 g to 1500 g |
| Supply Voltage | 5.0 Vdc typ., 12.0 Vdc max. |
| Null Offset | ±15 mV |
| Linearity | ±1.5% Span, BFSL |
| Null Shift over Temperature | ±0.5 mV typ. |
| Sensitivity Shift over Temperature | ±5.5% span |
| Input Resistance | 4.0 kOhm min., 5.0 kOhm typ., 6.0 kOhm max. |
| Output Resistance | 4 kOhm min., 5 kOhm typ., 6 kOhm max. |
| Overforce | 4,500 g |
| ESD | 8 kV |
| Operating Temperature | -40 °C to 85 °C [-40 °F to 185 °F] |
| Storage Temperature | -40 °C to 100 °C [-40 °F to 212 °F] |
| Vibration | 10 Hz to 2 kHz, 20 g, sine |
| Shock | 150 g, 6 ms, half sine |
| Solderability | 5 s at 315 °C per lead |
| Availability | Global |
| Comment | MCTF 20 Million at 50 °C |
| UNSPSC Code | 411121 |
| UNSPSC Commodity | 411121 Transducers |
| Package Type | Tube |
| Series Name | FSS |
