LED显示屏制造室内全彩表贴P6高清现货工程亮化
价格：电议
地区：广东 深圳市
电 话：86 0755 29766605
传 真：86 0755 27804890
-
图文详情
-
产品属性
-
相关推荐
室内显示屏主要技术参数(P6全彩)
MAIN TECHNICAL PARAMETERS FOR INDOOR LED DISPLAY(PITCH6)
技术参数Technical parameters | 单位UNIT | ID6FRGB8S3216 | |
单 元
模
块 | 物理点间距Pixel pitch | MM | 6 |
模块尺寸Panel size | MM | L192XH192X14 | |
物理密度Physical density | /M2 | 27778 | |
像素基色Pixel configuration | R/G/B | 1,1,1 | |
驱动方式Driving method | 1/8恒流扫描Constant current 1/8scan | ||
LED封装方式LED Encapsulation | DIP | 3528 | |
显示分辨率Display resolution | DOTS | 32X16=512dots | |
模块重量Module weight | KG | 0.15 | |
模块接口Module port |
| HUB75 | |
模块工作电压Module working voltage | VDC | 5 | |
模块功耗Module consumption | W | 18 | |
|
| ||
显
示
屏 | 视距Option distance | M | 6-78 |
每平米模块数Every square metre module | PCS | 54.25 | |
模块视角Viewing angle | Deg. | H120 V120 | |
功耗Maximum power | W/ M2 | 1000 | |
驱动器件Driving device |
| 16126 | |
换帧频率Frame Frequency | HZ/S | ≥60 | |
刷新频率Refresh frequency | HZ/S | ≥400 | |
白平衡亮度Equilibrium brightness | CD/ M2 | ≥1800 | |
工作环境温度Working environment temperature | 0C | -20~60 | |
工作环境湿度Working environment humidity | RH | 10%～90% | |
屏体工作电压Display working voltage | VAC | AC46～54HZ，220V±15%/110V±15% | |
白场色温Colour temperature |
| 6500K-9500K | |
灰度/颜色Gray scale/color |
| ≥16.7M color | |
输入信号Input signal |
| RF\ S-Video\ RGB etc | |
控制系统Control system |
| PCTV非线性卡nonlinearity card+DVI显卡display card+Linsn control system | |
平均无故障时间Mean free error time | HOURS | ＞5000 | |
寿命Life | HOURS | 100000 | |
杂点率Lampfailure frequency |
| ＜0.0001 | |
抗干扰Antijam |
| IEC801 | |
安全Safety |
| GB4793 | |
抗电击Resist the electricity |
| 1500V last 1min无击穿及飞狐No breakdown | |
屏体重量Steel box weight | KG/ M2 | 50（标准箱体standard steel box） | |
漏电电流Earth leakage current | mA |
| |
IP等级IPrating |
| The back IP40，The front IP50 | |
箱体尺寸Steel box size | mm | L960Xh768x100 | |
|
| ||
