供应高、GPS时钟模块
价格:电议
地区:
电 话:86 0755 26416960
手 机:13902960406
传 真:86 0755 26417089

SL-GMM-001is an ultrasmalldisciplined oscillator time and frequency reference platform. With its size,simpleinterface, andoutstanding holdover performance, the SL-GMM offers breakthrough price-performance in an adaptable, high-performance system.



FEATURES

·Provides 10 MHz & 1PPS

·Takes two external references.

·Outputs Synchronized to external reference

·Excellent Phase noise

·Holdover to meet Specifications

·Serial Port UART, NMEA Protocol

·Supply +5V (+3.3V optionally)





APPLICATIONS



·WiMAX/LTE Mobile Base Station Timing



·Broadcast (DVB/DVB-H, DAB, and DTV)



·Cellular Base Station (CDMA, TDMA, and UMTS)



·Fixed Wireless (MMDS, LMDS, and Wireless Local Loop)



·Asset Location, E911







PARAMETER







ENVIRONMENTAL SPECIFICATIONS



·Operating temperature: 10°C to +70°C (others available on request)



·Operating altitude:             200 ft to 40,000 ft (12,200 meters)



·Operating humidity              90%, Noncondensing





Frequency accuracy



·≤1E12 (24 hour average) when locked to GPS;



·<2E10 (Instantaneous);







Timing accuracy:



·+-50 ns RMS between units over any 20 minute interval (under limited tempe-rature variations);



·Programmable offset from GPS in 1nsec steps





Communication protocol



·NMEA0183.



·Other communication protocols available on request



更多详细信息,请联系carol@hwiteck.com
