ECLIPSE LV150金相尼康显微镜

ECLIPSE LV150金相尼康显微镜

The ECLIPSE LV Series realizes an unprecedednted level of versatility based on the new concept module design. The ECLIPSE LV150 is a new industrial-use microscope that flexibly responds to observation needs in development, quality management and inspecting manufacturing processes.

• The maximum sample height can be increased to 82mm from 47mm by inserting the LV-CR Columu Riser 35 between the main body and arm of the microscope.
  Use of non-Nikon stages, such as the Suruga Seiki B23-60CR, in combination with the LV-SUB Substage 2 allows the microscope to handle thicker samples of up to 116.5mm.
  PRIOR ProScan II motorized stage system can also be attached.
• Observation with first-order red compensator, UV polarizing, and epi-fluorescence observation with UV excitation, in addition to brightfield, darkfield, DIC, simple polarizing, epi-fluorescence （excitation using visible light） and double-beam interferometry are all possible.
• Although the LV-LH50PC Precentered Lamphouse is 12V-50W, the brightness is equivalent to or higher than that of 12V-100W.
• The eco glass used in the CFI LU Plan Fluor and L Plan EPI CR series does not contain harmful substances such as lead and arsenic.
•

ECLIPSEECLIPSE LV150金相尼康显微镜 LV系列unprecedednted水平的多功能性实现了一种基于新理念的模块设计。ECLIPSE LV150是一个新的拥有工业使用显微镜,灵活地响应观测发展的需要,制造过程的质量管理和检查。

?样本高度可以增加到82 mm来自47个mm插入lv cr Columu立管35之间的主体和手臂的显微镜。

使用非尼康阶段,如骏河精B23-60CR,结合lv子亚阶2允许显微镜来处理样品的厚116.5毫米。

ProScan之前II机动阶段系统也可以被附加。

?观察与一阶红光补偿、UV偏振和epi荧光观察紫外线激发,除了brightfield,暗视野,DIC,简单的偏振,epi荧光（激发使用可见光）和双光束干涉法都是可能的。

尽管LV-LH50PC?Precentered灯箱是12 v-50w,亮度相当于或高于12 v - 100 w。

?eco玻璃用于CFI LU计划萤石和L计划EPI CR系列不含有害物质,如铅和砷。
