IS1A 10 P18 1-dimensional, ±10°, 4...20 mA
IS1A 45 P18 1-dimensional, ±45°, 4...20 mA
IS1A 60 P18 1-dimensional, ±60°, 4...20 mA
IS2A 10 P18 2-dimensional, ±10°, 4...20 mA
IS2A 10 P18 2-dimensional, ±10°, 4...20 mA, 0,1° Calibration-Accuracy
IS2A 45 P18 2-dimensional, ±45°, 4...20 mA
IS2A 60 P18 2-dimensional, ±60°, 4...20 mA

Measurement axes 1 axis (IS1A xx P18), 2 axis (IS2A xx P18)
Measurement ranges         ±10°           /     ±45°     /   ±60°
Resolution (at zero point)         0,01°          /     0,05°    /   0,05°
Calibration accuracy (at 25° C)    ±0,1°, ±0,3°     /     ±0,7°    /   ±1,5° (zero point and accumulated values)
Nonlinearity (sine) Max.   ±0,2°       /     ±0,3°     /   ±0,4°
Temperature coefficient (zero point) Max. ±0.009 °/K / ±0.009 °/K / ±0.009 °/K
Cross Sensitivity Max. 5%
Critical frequency typ. 18 Hz
Operating temperature -40 °C to +80 °C
Characteristics
Interface current loop 4...20 mA ; max. permitted Burde-Resistor = 250 Ohm
Electrical Parameters
Supply voltage 10,5 V DC to 30 V DC
Current consumption < 25 mA

Connector sensor connector  5-pole (M12) IEC 61076-2-101, IEC 60947-2
Degree of protection IP65/67 min.locking torque of connector 0,9 Nm
Shock survival Max. 3,500 g
Dimensions 58 mm x 90 mm x 31 mm
Mass about 200 g
