美国MAC电磁阀说明书58D-83-RA
平衡提升阀设计便于在任何端口上使用与6个功能相同的阀连接到真空，
压力或堵塞。 管道如下图所示。
堆叠身体模型
阀体之间的可互换功能板允许选择任一个
3路常闭或3路常开操作。
The patented MACSOLENOID? with its non-burn out feature on AC service.
? Six valve functions with one individual valve.
? Individual, stacking body & add-a-unit manifold base capability.
? Use on lube or non-lube service.
? Extremely rapid response and cycle rate.
? Various types of manual operators and electrical enclosures.
? Extremely long service life.
? Optional low wattage DC solenoids down to 1 watt.
技术参数：
介质 压缩空气，真空或惰性气体
压力范围 真空到 120PSI
流量范围 1.8W:0.18Cv,  5.4W:0.2Cv,
电压范围 正常电压的-15%到+10%
功耗 1.8 to 12.7W
反应时间 24V(5.4W)  通电: 6ms    断电: 2ms 120/60 通电 3 ~ 8ms    断电:2 ~7ms
速度 14000 次/分钟
The MAC 100 Series is a direct solenoid operated 3-way poppet valve.
It features a short stroke solenoid, a balanced poppet and powerful return spring.
These features translate into high shifting forces,
fast consistent response times, and long life.
Our unique balanced design means versatility in piping -
the valve can be configured as a 3-way or 2-way -
normally closed or normally open or can be used for vacuum, diverter,
