兼容ZXSC400的LED恒流升压IC

       The YP6303 is a voltage mode boost converter in the SOT23-6 package.Its low feedback voltage allows the current in a chain of LEDs to be set and accurately monitored with a single resistor giving minimal losses. Its excellent load and line regulation means that for the full supply range from lithium-ion cells, the LED current will typically change by less than1％Using high efficiency switching transistors or the other general switching transistors with ratings of 20V and higher allow many LEDs to be chained in series for the best LED current matching possible.

        0.9V to 13V supply range, maxim input voltage to 15V

        Pin to pin compatible with ZETEX’s ZSXC400

     Applications: White LED backlighting for colour LCD panels;   General LED backlighting;   High performance white LED flashlights;   General LED driving from batteries

    我司同类系列：

       YP6158  兼容Zetex 310的LED升压控制，SOT23-5; 0.8~13Vin

       YP6165  LED手电筒升压IC  1~1.5Vin(或更高)推白光LED SOT-23

       YP6167三通道5.5~17Vin,Vout可达17V，Io 200mA SOP16/SSOP16，主要应用于各类装饰灯具。

    YP6172 PWM  6~50Vin  Io恒流20~150mA  2通道SO-8 QFN2X2，主要应用于DVDLCDTV背光驱动，室内灯等

       YP6175  PWM 6~50Vin  Io恒流10~60mA  6通道QFN3X3;  LED照明，广告牌DVD LCDTV背光.

       YP6179 4.5~25Vin 8通5~30mA恒流LED保护，QFN4X4-20;主要应用于LED手电筒,背光源.

       YP6190 2.7~10Vin 18Vout/20mA恒流白光LED Driver with OVP  SOT26

       YP6302 0.9~10Vin , Io=20mA可驱动多颗LED升压，可兼容ZETEX ZXSC380 SOT23封装

   详细规格书请参阅：https://www.yuketek.com/product/16.html
