产品规格:
类型：插墙试，
FEATURE:
Constant Voltage Mode(C.V.),Super Mini Size and Easy Portable＆convenient plug in,Wall Mount Type.
APPLICATION:
Lithium Ion Battery Charger,Digital Camera,CD-ROM and HUB,ADSL AP,Phone (CDMA MOBILE),MP3/MP4,Mini Note Book PC,Tester Machine,LCD Monitor etc.
INPUT/OUTPUT SPECIFICATIONS:
Input voltage: AC 100V～240V,50/60Hz
Range Voltage: AC 90V～264V,47/63Hz
Output Power:6W
Output voltage and current: 3V～24V, 0.1A～2A
Over Current Protection: 120%
Over Voltage Protection: 120%
Short Protection: Auto Recovery
Load Regulation:±5%
GENERAL SPECIFICATIONS:
Operating Temperature:0 ~ 40℃
Operating Relative Humidity:5 ~ 95%RH
Storage Temperature: -20～85℃
Withstanding Voltage: AC3000V/Min(between Input& Output) 5mA
Insulation Resistance: DC 500V 100MΩ(between Input & Output)
Efficiency: 80% MIN
SAFETY: PSE/UL/CUL/FCC/CCC/BSMI/BS/EK/GS/
SIZE:L*W*H=58*37*24mm
