SEMTECH原装行货RCLAMP0521P.TCT  TVS - 二极管批发

产品信息

• 标准包装：1
• 类别：过电压，电流，温度装置
• 家庭：TVS -二极管
• 系列：RailClamp®
• 电压-反向隔离（标准值）：5V
• 电压-击穿：6V
• 功率（瓦特）：100W
• 电极标记：双向
• 安装类型：表面贴装
• 封装/外壳：0402（1005公制）
• 供应商设备封装：SLP1006P2
• 包装：Digi-Reel®
• 其它名称：RCLAMP0521PDKR
•

深圳市富昌芯科技有限公司

联系人：杜小姐/李小姐

直线：  28556006

手机：     18948193967

Q Q：274320520       154

传真：

邮箱：

深圳市富昌芯阿里诚信通旗舰店：https://fchangx.cn.1688.com

地址：深圳市福田区振华路45号汽车大厦A栋1213

用途:DVI接口浪涌保护器件 超低电容 1线ESD保护;封装:SLP1006P21线ESD保护 ;小包装3000盘;RailClamps are ultra low capacitance Transient Voltage
Suppressors (TVS) designed to protect high speed data
interfaces. This series has been specifically designed to
protect sensitive components which are connected to
high-speed data and transmission lines from overvoltage
caused by ESD (electrostatic discharge), CDE (Cable
Discharge Events), and EFT (electrical fast transients).
The RClamp®0521P has a maximum capacitance of
only 0.50pF. This allows it to be used on circuits operating
in excess of 3GHz without signal attenuation. They
may be used to meet the ESD immunity requirements of
IEC 61000-4-2, Level 4 (±15kV air, ±8kV contact
discharge).
The RClamp0521P is in a 2-pin SLP1006P2 package
measuring 1.0 x 0.6 x 0.5mm. The leads are spaced
at a pitch of 0.65mm and feature a lead-free finish.
Each device will protect one high-speed line operating
at 5 volts. It gives the designer the flexibility to protect
single lines in applications where arrays are not practical.
The combination of small size, low capacitance,
and high ESD surge capability makes them ideal for
use in applications such as cellular phones and digital
video interfaces.
Applications
Mechanical Characteristics
Cellular Handsets & Accessories
Digital Visual Interface (DVI)
Display Port
MDDI Ports
USB Ports
PCI Express
Serial ATA
