Reverse       Breakdown      Breakdown                  Maximum              Peak       Reverse
           Type Number           Stand-Off      Voltage        Voltage        Test       Clamping            Pulse       Leakage
                                  Voltage       Min. @I                      Current
                                                       T      Max. @ IT                 Voltage @IPP         Current     @VRMW

        (Uni)         (Bi)        VRMW(V)      VBR MIN(V)     VBR MAX(V)     IT (mA)       VC(V)              IPP(A)      IR(uA)
     P6KE22 P6KE22C  17.8  19.8                                  24.2 1.0  31.9                               18.8  5.0
     P6KE22A P6KE22CA  18.8                      20.9 23.1 1.0 30.6  19.6 5.0
     P6KE24 P6KE24C  19.4  21.6                                  26.4 1.0  34.7                               17.3  5.0
     P6KE24A P6KE24CA  20.5                      22.8 25.2 1.0 33.2  18.1 5.0
     P6KE27 P6KE27C  21.8  24.3                                  29.7 1.0  39.1                               15.3  5.0
     P6KE27A P6KE27CA  23.1                      25.7 28.4 1.0 37.5  16.0 5.0
     P6KE30 P6KE30C  24.3  27.0                                  33.0 1.0  43.5                               13.8  5.0
     P6KE30A P6KE30CA  25.6                      28.5 31.5 1.0 41.4  14.5 5.0
     P6KE33 P6KE33C  26.8  29.7                                  36.3 1.0  47.7                               12.6  5.0
     P6KE33A P6KE33CA  28.2                      31.4 34.7 1.0 45.7  13.1 5.0
     P6KE36 P6KE36C  29.1  32.4                                  39.6 1.0  52.0                               11.5  5.0
     P6KE36A P6KE36CA  30.8                      34.2 37.8 1.0 49.9  12.0 5.0
     P6KE39 P6KE39C  31.6  35.1                                  42.9 1.0  56.4                               10.6  5.0
     P6KE39A P6KE39CA  33.3                      37.1            41.0 1.0  53.9                               11.1  5.0
     P6KE43 P6KE43C  34.8  38.7                                  47.3 1.0  61.9                                9.7  5.0
     P6KE43A P6KE43CA  36.8                      40.9 45.2 1.0 59.3  10.1 5.0
     P6KE47 P6KE47C  38.1  42.3                                  51.7 1.0  67.8                                8.8  5.0
     P6KE47A P6KE47CA  40.2                      44.7 49.4 1.0 64.8  9.3  5.0
     P6KE51 P6KE51C  41.3  45.9                                  56.1 1.0  73.5                                8.2  5.0
     P6KE51A P6KE51CA  43.6                      48.5 53.6 1.0 70.1  8.6  5.0
     P6KE56 P6KE56C  45.4  50.4                                  61.6 1.0  80.5                                7.5  5.0
     P6KE56A P6KE56CA  47.8                      53.2 58.8 1.0 77.0  7.8  5.0
     P6KE62 P6KE62C  50.2  55.8                                  68.2 1.0  89.0                                6.7  5.0
     P6KE62A P6KE62CA  53.0                      58.9 65.1 1.0 85.0  7.1  5.0
     P6KE68 P6KE68C  55.1  61.2                                  74.8 1.0  98.0                                6.1  5.0
     P6KE68A P6KE68CA  58.1                      64.6 71.4 1.0 92.0  6.5  5.0
     P6KE75 P6KE75C  60.7  67.5 82.5 1.0 108  5.6  5.0
     P6KE75A P6KE75CA  64.1                      71.3 78.8 1.0 103  5.8  5.0
     P6KE82 P6KE82C  66.4  73.8                                  90.2 1.0  118                                 5.1  5.0
     P6KE82A P6KE82CA  70.1                      77.9 86.1 1.0 113  5.3  5.0
     P6KE91 P6KE91C  73.7  81.9 100 1.0 131  4.6  5.0
     P6KE91A P6KE91CA  77.8                      86.5 95.5 1.0 125  4.8  5.0
     P6KE100 P6KE100C  81.0                      90.0            110           1.0          144                4.2         5.0
     P6KE100A P6KE100CA  85.5                    95.0 105 1.0 137  4.4  5.0
     P6KE110 P6KE110C  89.2                      99.0            121           1.0          158                3.8         5.0
     P6KE110A P6KE110CA  94.0                     105            116           1.0          152                3.9         5.0

所有产品都有SGS，全部符合ROHS标准（环保标准），还提供防雷方案设计、技术支持，热诚欢迎大家与我们公司联系业务。

具体价格,请来电咨询 .
