All values are typical at 25ºC and at 15 Vdc excitation unless otherwise stated. Measurement Specialties, Inc. reserves the right to update and
change these specifications without notice.
Measurement Specialties, Inc. 1000 Lucas Way Hampton, VA 23666 USAwww.meas-spec.com757--745-8008 Fax 757-766-4297
- 2 -
Maximum over load: 250% of range
Recommended Excitation: 5 Vdc
Full Scale Output span (Bridge Output): 20 mV/V +/- 20%
Output at No Load (Zero Output): +/- 15 mV/V
Combined Nonlinearity, Hysteresis and Nonrepeatability +/ - 1% FSO
Thermal Zero Shift within Operating Temperature Range +/- 8% FSO
Thermal Sensitivity Shift: +/- 0.05% /C
Operating Temperature Range: 0ºC to 50ºC
Storage Temperature -40ºC to 85ºC
Impedance In: 3 K ohm nominal
Impedance Out: 2.2 K ohm nominal
Deflection at Rated Load < 0.05 mm nominal
Isolation Resistance: > 50 Megohm nominal at 250 Vdc
Humidity 0 to 90 % RH
Cycle Life Expectancy: Essentially Unlimited
Note: Positive output in compression.
Note: +/- 5% FSO Zero trim available: Consult factory
Note: Low cost connectors available at extra charge for high volume applications: Consult factory.
