=====================产品描述=====================
产品技术特性Technical Characteristics
·电气特性Electrical Characteristics | ||||
NO. | ltem | Unit | Parameter | |
1 | T8 1.2米无眩光灯管 | mm | φ26 | |
2 | 工作电压Operating Voltage | V | AC100-240 | |
3 | 工作频率Operating Frequency | Hz | 50/60 | |
4 | 工作功率Operating Power | W | 18 | |
5 | 功率因数Operating Factor | / | >0.9 | |
·光学特性Photometric Characteristics | ||||
1 | LED数量LED QTY | Pcs | 120 | |
2 | 光通量 Luminous Flux | lm | 1550-1650 | |
3 | 发光角度Viewing Angle | ° | 120 | |
4 | 光效 Luminous Efficient | Lm/W | 》87 | |
5 | 色温 Color Temperature | K | 5500-6000正白 2700-3300暖白 | |
6 | 寿命 Working Life | H | >30000 | |
·环境范围EnvironmenntialRange | ||||
1 | 工作条件Operating Range | °C | -20~+40℃ | |
2 | 工作湿度Operating Humidity | RH | <60% | |
3 | 存储条件Storage Range | °C | -20~+60℃ | |
4 | 存储湿度Storage Humidity | RH | 35%---45% | |
·尺寸规格Dimensions | ||||
1 | 灯管尺寸Fluorescent Lamp Size | mm | Φ26×1198mm | |
2 | 包装尺寸Pachage Size(长×宽×高) | mm | 1270×225×145mm | |
3 | 每箱数量QTY Of Each Carton | Pcs | 15 | |
4 | 每箱净重Net Weight | Kg |
| |
5 | 每箱体毛重Gross Weight | Kg |
|
