Features / 特色

防水密封能預防因焊接或清理過程中的汙染物 Sealed against solder and cleaning process contaminants

翹板,底座和銅頭都符合UL94V-0 Rocker, case & bushing UL 94V-0

使用面積小節省PCB上的空間 Compact size and small footprint save PCB space

Applications / 應用範圍

電信 Telecommunication 儀器.測試設備 Instrumentation 電腦及其週邊

SPECIFICATION

Mechanical life:50,000 make-and-break cycles.

Circuit:SPDTContact resistance:20mΩmax. initial @ 2-4VDC 100mA for both silver and gold plated contacts.

Insulation resistance:1,000MΩmin.

Dielectric strength:1,000 Vrms min.@sea level.

Degree of protection:IP 67
