Features and benefits
  Range up to 6m
  2 mm range accuracy
  Easy remote operation, diagnosis and adjustment with PC, with analog display(option)
   Low processing power
  Capable 2-wire, loop powered, intrinsically safe
  inner temperature compensation to ensure accuracy of measurement
  Non-contact measurement
  Easy mounting via 1½ NPT
  Low cost
Application
Continuous, non-contact level measurement in fluids,
pastes, sullies and coarse bulk materials
Characteristics
Measuring Range Solids applications: 6m (transducer dependent)
Liquid applications: 3m (transducer dependent)
Measuring Resolution 1.5mm
Accuracy 0.25% of range or 2mm, whichever is greater
Max. Pulse Frequency 50KHz
Operating Temperature -20..+80℃
Operating Pressure 0.7..3 mbar
Power Supply 15..30V
Power Consumption 20 mW ... 500 mW
PCB Size Driver board(Φ:20mm), Main CTL board(Φ:55mm)
PCB Material FR4
